In June 2017, the American Society of Civil Engineers (ASCE) published an updated edition of ASCE 7, 'Minimum Design Loads and Associated Criteria for Buildings and Other Structures,' (ASCE 7-16). Because ASCE 7-16 is referenced in the International Building Code,® 2018 Edition (IBC 2018) as the basis for design wind-uplift load determination for all roof assembly types except asphalt shingles and tile, you should be aware of the changes.
ASCE 7-16
ASCE 7-16's design wind-uplift load procedures are described and the basic design wind speed maps are provided in Chapter 26-Wind Loads: General Requirements. Design wind-uplift loads for roof assemblies typically are determined using ASCE 7-16's Chapter 30-Wind Loads: Components and Cladding.
Chapter 30 provides seven methods—referred to as 'Parts'—for wind load determination. Part 1 applies to low-rise, enclosed or partially enclosed buildings. Part 2 is a simplified approach applicable to low-rise, enclosed buildings. Part 3 applies to enclosed or partially enclosed buildings higher than 60 feet. Part 4 is a simplified approach applicable to enclosed buildings higher than 60 feet but less than 160 feet in height. Part 5 applies to open buildings of all heights. Part 6 applies to building appurtenances, such as roof overhangs, parapets and rooftop equipment. And Part 7 applies to nonbuilding structures, including rooftop solar panels.
Part 2 and Part 4 apply to most buildings and likely will be used by most roof system designers. These simplified approaches include tables in Chapter 26 and Chapter 30 instead of analytical calculations.
241 Chapter 26 WIND LOADS: GENERAL REQUIREMENTS 26.2 DEFINITIONS The following defi nitions apply to the provisions of Chapters 26 through 31: APPROVED: Acceptable to the authority having jurisdiction. Also included is a report, 'Probabilistic Tsunami Design Maps for the ASCE 7-16 Standard,' which was prepared for the Structural Engineering Institute by researchers developing the Tsunami Design Geodatabase. This report describes the development of the 2,500-year probabilistic tsunami design zone maps and is suitable as a user manual. ASCE 7-16: Changes to Wind Calculations for Rooftop Solar Joe Cain, P.E. Chair, SEIA Codes & Standards Working Group David Banks, PhD, P.Eng Principal Cermak Peterka Petersen (CPP).
Significant changes
Comparing ASCE 7-16's wind-uplift design procedures with those of the previous version, ASCE 7-10, reveals several notable changes.
ASCE 7-16's basic design wind speed maps differ from ASCE 7-10's maps. Although the wind speeds along the U.S. Atlantic and Gulf of Mexico hurricane coastline are similar, ASCE 7-16's wind speeds in the central U.S. are slightly lower and in the West are notably lower than ASCE 7-10's wind speeds. Also, ASCE 7-16's maps include midpoint indicators between the maps' wind speed contours. Interpolation between the wind speed contours is permitted.
ASCE 7-16's external pressure coefficients are generally higher than those of ASCE 7-10. ASCE 7-16's Zones 1, 2 and 3 external pressure coefficients have increased about 70 percent, 28 percent and 14 percent, respectively, from ASCE 7-10. These external pressure coefficient increases generally will result in higher design wind-uplift loads in ASCE 7-16's Zones 1, 2 and 3 than ASCE 7-10's zones. ASCE 7-16 also includes a new Zone 1' pressure coefficient that is about a 10 percent reduction from ASCE 7-10's Zone 1.
